Availability: In Stock (Same Day Despatch) The AT-VM95C, the new Audio-Technica entry model Conical cartridge will replace the legendary AT90 Series models such as AT91, AT91R and CN5625AL Also the AT-VM95C is a “budget” cartridge featuring a conical stylus, the compatibility in the range will allow to upgrade with any of the 4 other LP styli of the Series such as Elliptical, Elliptical Nude, Microlinear and Shibata. Aluminium cantilever 4.0mV output voltage Compatible body with all VM95 Series stylus assemblies Replacement for AT91, AT91R and CN5625AL VM95 Series – Styli compatibility Every cartridge diamond stylus becomes worn after a period of play. Around 500 hours for a conical stylus, 300 hours for an Elliptical stylus, 1000 hours for a Microlinear stylus, and 800 hours for a Shibata stylus. Our VM95 Series dual moving magnet cartridges can be used almost forever by replacing the interchangeable stylus. It is no longer necessary to purchase a complete cartridge when your diamond is worn out, you can simply buy the matching replacement stylus, but also enjoy the experience of upgrading your cartridge with a different stylus. The six models of VM95 Series cartridges all use the same electromagnetic engine-body, therefore each of the six replacement styli are perfectly compatible. AT-VMN95C AT-VMN95E AT-VMN95EN AT-VMN95ML AT-VMN95SH AT-VMN95SP Features The benefit of conical styli, even if the cartridge is “lean”, is the ball surface of the stylus touches the groove of vinyl records precisely. Conical Bonded Stylus No use of nuts VM95 Series cartridges features two M2.6 threaded inserts allowing the installation of the cartridge onto tonearm or removable headshell without the use of nuts.Each cartridge is provided with one pair of 8mm M2.6 screws, one pair of 11mm M2.6 screws and two plastic washers. Specs Model AT-VM95C Type VM Stereo Dual Magnet Mounting 1/2” centres Frequency Response 20 – 20,000 Hz Channel Separation 18 dB (1 kHz) Output Channel Balance 2.5 dB (1 kHz) Output Voltage 4.0 mV (@ 1 kHz, 5 cm/sec) Vertical Tracking Angle 23° Vertical Tracking Force Range 1.8 – 2.2g (standard 2.0 g) Stylus Shape Conical Stylus Size 0.6 mil Stylus Construction Bonded Round Shank Cantilever Aluminium Pipe Coil Impedance 3.3 kΩ (1 kHz) Coil Inductance 550 mH (1 kHz) DC Resistance 485 Ω Static Compliance 17 x 10 – 6 cm / dyne Dynamic Compliance 6.5 x 10 – 6 cm / dyne (100 Hz) Wire Used for Coil T.P. Copper Recommended Load Impedance 47,000 Ω Recommended Load Capacitance 100-200 pF Cartridge Weight 6.1g Dimensions 17.2 x 18.9 x 28.3 ( H x W x D mm) Replacement Stylus AT-VMN95C Accessories Included Two 11 mm installation screws; Two 8 mm installation screws; Two washers
