Specifications Model EVO 300 Hybrid Poweramplifier Power 8 Ohm > 100 Watts per stereo channel (typical 115 Watts) > 220 Watts per mono channel (typical 245 Watts) Power 4 Ohm > 150 Watts per stereo channel (typical 160 Watts) > 300 Watts per mono channel (typical 303 Watts) Frequency Response 10 Hz – 80 kHz +/- 3 dB THD with AABB < 0.2% 100W @ 8 Ohm (stereo) < 0.2% 245W @ 8 Ohm (mono) S/N Ratio -105dB (A-Weighted) Input Impedance 32 kOhm (RCA), 49 kOhm (XLR) for stereo 18 kOhm (RCA), 50 kOhm (XLR) for mono Input Sensitivity 805 mV (RCA), 901mV (XLR) for stereo 1330 mV (RCA), 1340 mV (XLR) for mono Total Gain 30 dB (H), 24 dB (L) Power Consumption 104 Watts (no signal in); 645W@4R Weight Net weight: 68.3 lbs / 31 kg Shipping Weight: 77.2 lbs / 35 kg Dimensions 15.9" x 15.2" x 8.1" / 405 x 385 x 205 mm (L x W x H) Shipping dimensions 22.7" x 18.4" x 12.4" / 578 x 468 x 316 mm (L x W x H) Inputs 1 pairs Stereo RCA, 1 pair Stereo XLR Outputs Stereo & Mono output & Trigger output Tube Complement 6 x 12AU7 Damping Coefficient 300 (1 kHz) for stereo 150 (1 kHz) for mono Manuals Reviews Since 2003 PrimaLuna has been building pure valve amplifiers with a clear mission: delivering high-performance valve-based audio components at affordable prices, resolving the reliability issues that had often dissuaded people from investing in the sonic beauty of valves. Our current, much-acclaimed EvoLution range spans 12 valve amplifiers – integrated amps, preamps and power amps across four price tiers – as well as a valve-based DAC. In 2021, we revolutionized the audio world with the PrimaLuna EVO 300 Hybrid Integrated Amplifier, marking our first venture into hybrid amplification. Partnering with Floyd Design, the solid-state development department of Durob, we combined the best of both worlds: the effusive fluidity of valves and the power and control of solid-state technology. Building on this success, our expert designers, led by Herman van den Dungen, have spent years perfecting our latest model – the PrimaLuna EVO 300 Hybrid Poweramplifier, launching in 2024! Why Choose the PrimaLuna EVO 300 Hybrid Poweramplifier? The EVO 300 Hybrid offers a unique blend of tube amplifier warmth with the robust performance of a MOSFET power amplifier. Here's why it's a game-changer: Tube Sound with Power and Control : Experience the lush sound of tubes combined with the power and efficiency of MOSFET technology. Advanced Design : Incorporates Junction FETs, hand-matched transistors, and a double pair of MOSFETs, all powered by a generously sized power supply. Superior Components : Includes PrimaLuna Silver Label tubes, Swiss DuRoch tinfoil capacitors, and Japanese Takman resistors, ensuring unparalleled sound quality and reliability. Meticulous Construction : Features hard wiring, heavy-duty anti-resonant PCB material, and thick copper tracks for the highest fidelity. Versatility : By enabling the mono function, users can use two PrimaLuna EVO 300 Hybrid Poweramplifiers as monoblock amplifiers, effectively doubling the power output and improving channel separation and soundstage. Power-Amp Tube Section: Separate high-voltage power supplies for each tube and channel. Premium Swiss and Japanese components for optimal performance. Power-Amp MOSFET Section: High-power transformers and capacitors for substantial output. Factory-matched MOSFETs and hand-made resonance-free output coil. Each power stage includes advanced protection circuits. General Features: Dual inrush protection circuits. Balanced (XLR) and unbalanced (RCA) inputs. Top-tier parts quality, inspected and matched for reliability and performance. Unmatched Sound Quality : The EVO 300 Hybrid Poweramplifier delivers a dynamic range, deep stereo imaging, expressive mid and high frequencies, and tight bass, offering a seamless sonic experience that truly captures the essence of your music. Are you ready to elevate your audio experience? Discover the PrimaLuna EVO 300 Hybrid Poweramplifier – a testament to our commitment to superior sound quality and innovative design.
