The Soundsmith Zephyr MkII phono cartridge employs “Trickle Down” Technology from a unique Energy Distribution System within the cartridge body as used in the Soundsmith’s well received high end Sussurro Cartridge. The Zephyr MkII is built using a selected “low mass contact line diamond” stylus design, mounted on an Aluminum cantilever capable of truly remarkable separation, sound stage and imaging. The composite body and unique energy distribution system contributes to the Zephyr MkIIs ability to produce high-end performance from a moderately priced cartridge. The Zephyr MkII will provide a level of clarity and beauty that will make you take out your record collection and listen to it all over again. Specs Cartridge Type: Fixed Coil Output: High Available As Dual Coil Mono: Yes Stylus:Ultra Low Mass Nude Contact Line Stylus Radius of curvature: 6 x 17 μm Cantilever: Aluminum Recommended Tracking force: 1.8 to 2.2 grams Effective tip mass: 0.32 mg Compliance: 10μm/mN (low compliance) Frequency response: 15-45,000 Hz ± 2.0 dB Channel Separation (stereo only): 1000 Hz >28 dB, 50-15,000 >25 dB Channel difference: <1.0 dB (Stereo), <0.5 dB (Dual Mono operation- w/optimal VTF setting) Output voltage: 2.4 mV Cartridge weight: 10.27 grams Loading: ≥ 47 kΩ
