The WPhono1 Mk2 is a phono stage with dedicated moving magnet and moving coil inputs. It features adjustable impedance and capacitance, per input, and RIAA active global feedback equalisation. In addition, this unit features a discrete, fully-balanced headphone amplifier with dedicated volume control and an output of 8W per channel. For analogue purists, this is the go-to phono amplifier from Waversa and with a compact form factor, will fit neatly into your existing set up. Main Features Compact Phono Equalizer with Headphone Amplifier MM/MC input Impedance and Capacitance Adjustment Fully Discrete Headphone Amplifier Exclusive Technologies Active Global Feedback Equalization – RIAA Full Discrete Headphone Amplifier with Volume Control Physical Characteristics Chassis: Aluminium Colour: Silver Input: RCA MM, RCA MC Output: XLR, RCA, Phone 6.3mm Dimension: W340xD230xH45mm Weight: 3.7 kg / 8.14 lbs. Power supply: Inbuilt, AC Input: 90V ~ 240V Adjustable MM/MC Specifications MM 22k – 33k – 47k – 100k Ohms / 20 – 330 pF MC 5 – 15 – 25 – 100 Ohms Gain: MM 40dB, MC 71dB RIAA Response +/- 0.1dB, 20 – 20kHz Note: not recommended for very low impedance cartridges Headphone Amp Specifications Fully Balanced Abyss Mosfet Output Stage 8w/ch
